MODEL

ALKO CONV220-48-40A

DC OUTPUT VOLTAGE

48VDC

CURRENT RANGE

40A

RATED POWER

2000W

VOLTAGE ADJ. RANGE

10%

DC  INPUT VOLTAGE RANGE

220VDC ( 180-320 VDC )

EFFICIENCY

89%

INRUSH CURRENT

0-12ADC

OVER LOAD

105 ~ 125% Rated out put Power

Protection type : Shut down o/p voltage,fe-Power on to Recovery

OVER VOLTAGE

58VDC HIGHT

Protection type : Shut down o/p voltage, re-power on to recover

OVER TEMPERATURE

80°C ±5°C (TSW1) detect on heatsink of power transistor

Protection type : Shut down o/p voltage, recovers automatically after temperature goes down

WORKING TEMP.

-20 ~ +60°C  (Refer to "Derating Curve")

WORKING HUMIDITY

20 ~ 90% RH non-condensing

STORAGE TEMP., HUMIDITY

-40 ~ +85°C , 10 ~ 95% RH

SAFETY STANDARDS

U60950-1 Approved

WITHSTAND VOLTAGE

I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

ISOLATION RESISTANCE

I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC / 25°C / 70% RH

DIMENSION (H*W*D)(MM)

Rack 19 inch 2U  (88*440*320)

WEIGHT (KG)

16
